ST06 U1 Thermal Protector
Technical description
Action temperature in 5°C
60 °C - 180 °C
Tolerance (standard)
(60-180) °C ± 5K
Reset temperature & Tolerance
≥ 35°C (≤ 95°C NST)
-50K ± 15K (≥ 100°C ≤ 180°C NST)
-50K ± 15K (≥ 100°C ≤ 180°C NST)
Thickness
6.8mm
Diameter
9.5mm
Length of the insulation cap
16mm
Resistance to impregnation
suitable
Applicable installation protection level
I+ll
Pressure resistance to the shell
600N
Standard lead wire
0.81 mm² / AWG18
Anti-Vibration performance (10 - 60 Hz)
100 m/s²
Insulation & Voltage resistance
2.0 kV
Reaction time
< 1 ms
Contact IR
≤ 50 mΩ
Operating voltage range AC/DC
Max. 500 V AC / 28 V DC
Rated voltage AC
250 V
Rated current AC cos ϕ = 1.0 /cycles
10.0 A / 10,000
Rated current AC cos ϕ = 0.6 /cycles
6.3 A / 10,000
Max. switching current AC cos ϕ = 1.0 /cycles
25.0 A / 100
Rated direct voltage
24.0 V
Rated DC
10.0 A
Note:
The product parameters are provided by Saftty's testing standards, and just for reference. The buyer is responsible for independent analysis, evaluation and judgment during design or use. For the data other than the above parameters, Saftty did not conduct any tests. and Saftty has the right to correct or change the data.
